Sanitary Pumps for Breweries

Brewing great beer requires more than quality ingredients and a carefully controlled recipe. Every piece of equipment that comes into contact with the product can affect consistency, sanitation and overall quality.

Pumps play an important role throughout the brewing process, moving everything from ingredients and wort to finished beer and cleaning solutions. Because these fluids are part of a consumable product, breweries need pumps designed to handle them efficiently while supporting strict sanitary requirements.

Why Sanitary Pump Design Matters in Breweries

Unlike many general industrial applications, breweries must pay close attention to how processing equipment affects the product. Pumps should be designed to minimize areas where product can collect, allow for effective cleaning and handle the fluid without unnecessarily affecting its characteristics.

The right sanitary pump can help breweries:

• Maintain consistent product quality
• Reduce the risk of contamination
• Protect shear-sensitive products and ingredients
• Simplify cleaning and sanitation
• Reduce product loss during transfer
• Improve process efficiency
• Handle a range of viscosities and flow requirements

From transferring ingredients to moving finished beer, different stages of the brewing process may require different pump technologies.

Graco SaniForce Pumps

Graco SaniForce sanitary pumps are designed specifically for food and beverage processing applications. The SaniForce line includes multiple pump technologies for transferring products ranging from low-viscosity liquids to thicker ingredients.

For breweries, SaniForce drum pumps can provide a convenient solution for transferring ingredients and other liquids from drums or containers into the production process. Sanitary connections and designs that allow easier disassembly help simplify cleaning and product changeovers.

Graco specifically identifies breweries, distilleries and wineries as applications for its sanitary electric drum pumps.

Potential brewery applications include:

• Ingredient transfer
• Drum and container unloading
• Flavoring and additive transfer
• Syrups and concentrates
• General sanitary fluid transfer

Moyno 500 Sanitary Pumps

The Moyno 500 Sanitary Pump combines compact construction with the advantages of progressive cavity pump technology.

Its positive displacement design provides accurate, repeatable and non-pulsating flow, making it well suited for applications where controlled transfer and gentle product handling are important.

Constructed with food-grade 316 stainless steel, the Moyno 500 Sanitary is designed to meet 3-A sanitary standards and uses elastomers that satisfy FDA requirements. A quick-disassembly clamp also makes cleaning and maintenance easier.

Potential brewery applications include:

• Flavorings and additives
• Metering applications
• Shear-sensitive fluids
• Viscous ingredients
• Filling and dispensing
• Cart-mounted sanitary transfer

FLUX

F / FP 427 Sanitary Pumps

When breweries need to transfer liquids directly from drums or containers, the FLUX F 427 and FP 427 provide another hygienic pumping option.

The F 427 is designed for sanitary transfer of food, beverage, cosmetic and pharmaceutical products. The pump can be quickly disassembled for thorough cleaning or sterilization, an important advantage when equipment is used with different products.

Its sanitary construction also eliminates difficult-to-access internal areas that could otherwise make thorough cleaning more challenging.

Potential brewery applications include:

• Drum and container transfer
• Liquid ingredients
• Flavorings
• Additives
• Low-viscosity beverage products
• Applications requiring frequent product changeovers

Unibloc Hygienic Pumps

Unibloc Hygienic Technologies offers sanitary positive displacement pumps designed for demanding food and beverage applications.

For breweries, Unibloc pumps can provide gentle, low-shear product handling while also supporting efficient cleaning. Unibloc specifically identifies brewery applications ranging from dry-hop recirculation to finished beer transfer.

Many Unibloc designs emphasize simplified maintenance and Clean-in-Place (CIP) or Clean-out-of-Place (COP) capability, helping processors reduce sanitation-related downtime.

Potential brewery applications include:

• Wort and product transfer
• Dry-hop recirculation
• Finished beer transfer
• Ingredient handling
• Higher-viscosity products
• Sanitary process applications

Verder Hygienic Pumps

Verder Hygienic Pumps offer several technologies for food and beverage processing, including Packo centrifugal, rotary lobe and twin screw pumps as well as Verderflex peristaltic and Verderair diaphragm pump options.

Packo sanitary centrifugal pumps are widely used in breweries, distilleries and other beverage-production applications. Depending on the pump and application, Verder solutions can be used across both hot and cold areas of the brewing process.

This broad range allows breweries to select pump technology based on the characteristics of each fluid and process rather than relying on one pump style throughout the facility.

Potential brewery applications include:

• Wort transfer
• Fermentation processes
• Filtration
• Filling
• Ingredient and additive dosing
• CIP systems
• Finished beverage transfer

Choosing the Right Sanitary Pump for a Brewery

There is no single pump that is ideal for every step of the brewing process. Selecting the right equipment depends on factors such as viscosity, temperature, flow rate, pressure, solids content, shear sensitivity and cleaning requirements.

For example, a sanitary centrifugal pump may be an efficient choice for moving larger volumes of low-viscosity liquids, while a positive displacement pump may be better suited for controlled transfer, viscous ingredients or shear-sensitive products. Drum pumps provide another option when ingredients need to be transferred directly from drums, totes or other containers.

Understanding the process is the first step toward selecting the right pump.

Sanitary Pump Solutions from CEJCO

CEJCO offers a range of sanitary and hygienic pumping technologies for breweries and other food and beverage processing facilities, including solutions from Graco, Moyno, FLUX, Unibloc and Verder.

Our team can help evaluate your application and determine the appropriate pump technology based on your process requirements, fluid characteristics and sanitation needs.

Looking for a sanitary pump for your brewery or beverage facility? Contact CEJCO to discuss your application.
